Straightaway 180

SKU STRAIGHTAWAY-180

The Straightaway 180 is a sophisticated and versatile top hung system designed for medium to heavy duty sliding doors up to 180kg. The system can easily accommodate sliding doors in a variety of architectural openings and is supplied with four wheeled hangers incorporating nylon coated wheels and precision ball bearings.

Overview

Top hung sliding system for timber or metal doors up to 180kg

  • Suitable for use both internally and externally
  • Smooth and quiet operation provided by anodised aluminium track and nylon wheeled hangers
  • Tracks can be mounted directly to the soffit or wall mounted using brackets
  • Hangers have vertical adjustment to ensure a perfect fit
  • Range of bottom guiding options available to achieve a clear threshold
  • Any number of doors can be used on single or multiple lines of track to cover the width of the opening
  • Telescopic opening options for 2 doors and 3 doors available



TECHNICAL SPECIFICATIONS
Weight
180
Thickness
35mm - 55mm
Height
3500mm
Closure Type
Sliding
Door Material
Metal
Timber
Fitting Position
Top Hung
